Characteristics
- Tobe used to measure the melting point of medicines, dye-stuffs and perfumes and other organic crystal substances to determine their purity.
- Visuallydetect the initial and final melting points of the
- Measuringthree samples at the same time and calculate the average value
- Usesilicone oil or water as heating-conducting
Specifications
| Parameters/Model | MP | MP-Y |
| Measuring range | Silicon oil : 40℃-280℃ | Water：40℃-90℃
Silicon oil：60℃-280℃ |
| Heating-conducting medium | Silicon oil | Water / Silicon oil |
| Measuring Mode | Visual (8x magnification window) | |
| Resolution | 0.1 ℃ | |
| Linear heating-up rate | 0.5℃/min, 1.0℃/min, 1.5℃/min, 3.0 ℃/min | |
| Accuracy | ≤200 ℃：±0.4℃；＞200 ℃：±0.7℃ | |
| Repeatability | 0.3℃ (heating rate: 1.0℃/min) | |
| Linear heating rate error | ±10% | |
| Capillary dimensions | Outer diameter: φ1.4mm Inner diameter: φ1.0mm
Length: 120mm |
|
| Number of capillary | 3 | |
| Height of sample | 3mm | |
| Interface | RS232，USB | |
| Display | LCD | |
| Power supply | 220V±22V，50Hz±1Hz，200w | 220V±22V，50Hz±1Hz，100w |
| Overall Dimensions | 390mm ×390mm ×520mm | |
| Weight (Gross) | 13kg | |
