Characteristics
- Measurementof light scatter and decay of the insoluble particles suspended in water or transparent
- Automaticrange switching, and multi point
- Equippedwith average measurement
- Compliantwith GLP Regulation and ISO
- Quantitativeanalysis of particle
Specifications
| Parameters/Model | OTBM-4000 | OTBM-2000 | OTBM-1000 | OTBM-500 | OTBM-200 | OTBM-100 |
| Light source | Tungsten halogen lamp (6V / 10W) | |||||
| Wavelength | 400nm-600nm | |||||
| Measuring mode | NTU, FTU, EBC, ASBC | |||||
|
Measuring range NTU |
0.000-50.00
50.01-200.0 200.1-2000 2000.1-4000 |
0.000-50.00
50.01-200 200.1-2000 |
0.000-50.00
50.01-200 200.1-1000 |
0.000-50.00
50.01-200.0 200.1-500 |
0.000-50.00
50.01-200.0 |
0.000-50.00
50.01-100.0 |
| Resolution | 0.001 | |||||
| Allowable error of indication | ≤±6% | |||||
| Zero Drift | ≤±0.3%FS | |||||
| Stability of indication | ≤±1%FS | |||||
| Repeatability | ≤0.5% | |||||
| Sample bottle | Φ 25 mm×95 mm | |||||
| Sample volume | 30–40 ml | |||||
| Calibration points | 7 | 6 | 5 | 4 | 3 | 3 |
| Display | LCD Touch Screen | |||||
| Interface | USB，U disk | |||||
| Data storage | 1000 sets | |||||
| Power supply | 220V±22V，50Hz±1Hz，30w | |||||
| Overall dimensions | 430mm×430mm×300mm | |||||
| Weight (Gross) | 9kg | |||||
