Characteristics
- Androidsystem with 1 inch touch screen, provides melting videos playback.
- 720PHD camera for clear
- UsePID & PWM to control
- Thelight source brightness and detection sensitivity can be adjusted to better measure dark color
- Theinstrument can measure 4 capillaries as the same
- Audittracking function is optional, which meets the relevant requirements of the National Pharmacopoeia, GMP, GLP, and FDA/21CFR Part 11, and has user management
Specifications
| Parameters/Model | MP-685 | MP-682 | MP-681 |
| Measuring range | Room temperature – 400℃ | Room temperature – 360℃ | |
| Measuring mode | Auto / Visual (HD camera, video capture, playback monitoring) | ||
| Measuring methods | 200 | 150 | 100 |
| Number of Users | 200 | 150 | / |
| Audit trail | Optional | Optional | / |
| Electronic Signature | Yes | Yes | / |
| Resolution | 0.01℃ | ||
| Linear heating-up rate | 0.1℃/min~20℃/min | ||
| Accuracy | ≤200℃ ±0.3℃ ; ＞200℃ ±0.5℃ | ≤200℃ ±0.4℃ ; ＞200℃ ±0.7℃ | |
| Repeatability | 0.3℃ (heating rate: 1.0℃/min) | ||
| Linear heating rate error | ±10% | ||
| Number of capillary | 4 | ||
| Capillary dimensions | Outer diameter: φ1.4mm Inner diameter: φ1.0mm Length: 90mm | ||
| Height of sample | 3mm | ||
| Operation System | Android | ||
| Data storage | 128G | 64G | |
| Display | 10.1 inch touch screen | ||
| Graph storage | 40000 sets | 20000 sets | 10000 sets |
| Interface | 1 x RS232，3 x USB，1 x RJ-45，WIFI | 1 x RS232，3 x USB | |
| Power supply | 100~240 V，50/60 Hz，150 w | ||
| Overall Dimension | 495mm×493mm×350 mm | ||
| Weight(Gross) | 5kg | ||
