Characteristics
- Imageprocessing and analysis, with video recording and
- Androidoperating system with large touch
- Equippedwith multi-point calibration function, observing with automatic mode or visual mode.
- Improvedaccuracy and reliability of the melting
- Itcan measure special samples that appear dark or opaque after melting, as well as samples that decompose during heating.
- Compliantwith the relevant requirements of the National Pharmacopoeia, GMP, GLP, and FDA/21CFR Part
Specifications
| Parameters/Model | MP-650A | MP-630A |
| Measuring range | Room temperature – 400℃ | |
| Measuring mode | Auto / Visual | |
| Measuring methods | 600 | 400 |
| Number of Users | 300 | 200 |
| Audit trail | Optional | Optional |
| Electronic Signature | Yes | Yes |
| Resolution | 0.01℃ | |
| Linear heating-up rate | 0.1℃/min~20℃/min | |
| Accuracy | ≤200℃ ±0.3℃ ; ＞200℃ ±0.5℃ | |
| Repeatability | 0.3℃ (heating rate: 1.0℃/min) | |
| Linear heating rate error | ±5% | |
| Number of capillary | 5 | 3 |
| Capillary dimensions | Outer diameter: φ1.4mm Inner diameter: φ1.0mm Length: 90mm | |
| Height of sample | 3mm | |
| Operation System | Android | |
| Data storage | 128G | |
| Display | 10.1 inch touch screen | |
| Interface | 1 x RS232，3 x USB，1 x RJ-45，WIFI | |
| Power supply | 100V~240VAC，50Hz/60Hz，150W | |
| Package Dimension | 495mm×493mm×350 mm | |
| Weight(Gross) | 5kg | |
