Auto defrost freezer, Forced-Air Circulation Suitable for hospitals,blood banks, epidemic prevention, animal husbandry areas,pharmaceutical companies and research institutes.Designed to store pharmaceuticals, medicine, vaccines, biological materials, testing reagents and laboratory materials.
Features of Auto defrost freezer
Temperature Control
- Microprocessor control, Large LED display inner temperatureclearly, and with easy viewing.
- Theinnertemperature can be adjustable at the range of -10°C~-30’C, with an increment of o.1°C.
- Multiple sensors to display or control the temperature.
- Lock and password for protection to prevent arbitrary adjustmentof operating parameters.
Safety Control
- Malfunction alarms: high temperature alarm, low temperaturealarm, Sensor failure.
- Over temperature alarm system, set the alarm temperature as
- Three alarming methods: buzzer alarming, digital flashing alarming and Remote alarm;Protection function: power-on delay, timebetween stops.
- 7 days Chart temperature recorder monitor system (Optional).
Ergonomic Design
- Safety door lock, preventing unauthorized access;Wide voltage design from 192V to 242V.
- Pressure-balanced port design, easy to open the door.
- Adjustable shelves design.
- Heavy type caster and locking adjustable screw, easy to move and fix.
Refrigeration System
- Highly efficient famous brand hermetically sealed CFC free compressor andfan;70mm thick foam insulation, better insulation effect, help to maintain temperature stability inside the freezer, Forced-Air Circulation for large airflow with special air ducts to guarantee inner temperature consistency.
- Monoblock refrigeration units, energy-efficient and easy for maintanance.
- HCFC refrigerant
| Model | LFZ-30U650A | LFZ-30U1100A | LFZ-30U1400A | |
| Technical Data | Cabinet Type | Upright | ||
| Climate Class | N | |||
| Cooling Type | Forced air cooling | |||
| Defrost Mode | Auto | |||
| Refrigerant | HC,R290 | |||
| Performance | Cooling performance(°C) | -25 | ||
| Temperature Range(°C) | -10～-30 | |||
| Power Supply(V/HZ) | 220/50 | |||
| Power(W) | 460 | 650 | 700 | |
| Power Consumption（kwh/24h） | 6.8 | 7.2 | 8.5 | |
| Control | Controller | Microprocessor (Dixell) | ||
| Display | LED | |||
| Material | Interior | Galvanized steel powder coating（white) | ||
| Exterior | Galvanized steel powder coating（white) | |||
| Dimensions | Capacity | 580 | 1050 | 1350 |
| Net/Gross Weight(approx) | 158kg/183kg | 228kg/263kg | 280kg/330kg | |
| Interior Dimensions(W*D*H) | 660x690x1401mm | 1180x690x1401mm | 1460x690x1401mm | |
| Exterior Dimensions(W*D*H) | 785x830x1965mm | 1305x830x1965mm | 1585x830x1965mm | |
| Functions | High/Low Temperature | Yes | ||
| Remote Alarm contact | Yes | |||
| Door open alarm | Yes | |||
| Door Lock | Yes | |||
| Accessories | Caster | Yes | ||
| Test Hole | Yes | |||
| Shelves/Inner Doors | 5/4 | 5/8 | 5/8 | |
| Foaming Door | Yes | |||
| Temperature Recorder | Optional | |||
