Adoption of low-temperature liquid circulation equipment of compression refrigeration methods can cool the tube, the reaction bottles directly and so on to have chemical reaction under low-temp and store chemical and biological products under low-temperature. Besides, it can also be combined with Rotary Evaporator, Vacuum Freeze-drying Box, and multi-purpose Circulating Water Vacuum Pump.
Features
- Large-capacity open bath combined with outside loop can not only be used as freezing tanks, but also provide cooling fluid outside.
- Digital setting and display of temperature, easy to operate.
- Refrigeration compressors and other key parts adopt products with famous brands of the United States, Germany, and France and have high reliability and efficiency.
- Circulating system adapts SUS 304, 316 and macromole anti corrosion substance, which can prevent rust, corrosion, and low temperature liquid pollution.
Specifications:
| Model |
LLCP-5-10 |
LLCP-5-20 |
LLCP-10-20 |
|
| Temp. Range(°C) |
-10~RT |
-20~RT |
||
| Temp. Stability(°C) |
±1 |
|||
| Cooling capacity (W) |
10°C |
1250 |
1150 |
1700 |
| 0°C |
970 |
880 |
1200 |
|
| -10°C |
650 |
600 |
700 |
|
| -20°C |
– |
320 |
370 |
|
| Flow(L/min) |
12 |
|||
| Lift(m) |
5~7 |
|||
| Bath volume(L) |
5 |
5 |
10 |
|
| Bath opening(mm) |
ф210×180 |
ф210×180 |
ф210×250 |
|
| Ambient temp.(°C) |
5~25 |
|||
| Power Supply(V/Hz) |
220/50 |
|||
| Overall Power(W) |
600 |
600 |
1100 |
|
| Case Material |
SPCC steel with powder coating |
|||
| Dimensions(mm)L×W×H |
465×325×730 |
465×325×730 |
510×365×800 |
|
| Weight(kg) |
41 |
41 |
50 |
|
| Model |
LLCP-10-30 |
LLCP-20-30 |
LLCP-30-30 |
LLCP-50-30 |
LLCP-100-30 |
|
| Temp. range(°C) |
-30~Room temp |
|||||
| Temp. stability(°C) |
±1 |
|||||
| Cooling capacity (W) |
10°C |
1860 |
2550 |
3240 |
10000 |
17600 |
| 0°C |
1240 |
1750 |
2820 |
7500 |
12000 |
|
| -10°C |
780 |
1070 |
1810 |
4600 |
7500 |
|
| -20°C |
310 |
720 |
1030 |
2570 |
6500 |
|
| -30°C |
50 |
300 |
520 |
1040 |
2900 |
|
| Flow(L/min) |
12 |
12 |
12 |
30 |
67 |
|
| Lift(m) |
5~7 |
5~7 |
5~7 |
10~12 |
22 |
|
| Bath volume(L) |
10 |
20 |
30 |
50 |
100 |
|
| Bath opening(mm) |
ф210×250 |
ф280×300 |
ф320×235 |
ф400×280 |
ф400×400 |
|
| Ambient temp.(°C) |
5~25 |
|||||
| Power Supply(V/Hz) |
220/50 |
380/50 |
||||
| Overall Power(W) |
1100 |
1400 |
1800 |
2900 |
5300 |
|
| Case Material |
SPCC steel with powder coating |
|||||
| Dimensions(mm) |
510×365×800 |
575×495×965 |
665×545×1010 |
1080×675×1305 |
1210×740×1400 |
|
| Weight(kg) |
50 |
90 |
100 |
300 |
400 |
|
| Model |
LLCP-30-40 |
LLCP-50-40 |
|
| Temperature range(°C) |
-40~Room temp |
||
| Temperature stability(°C) |
±1 |
||
| Cooling capacity (W) | -10°C |
3670 |
7205 |
| -20°C |
2310 |
4950 |
|
| -30°C |
1100 |
2450 |
|
| -40°C |
480 |
1500 |
|
| Flow(L/min) |
12 |
30 |
|
| Lift(m) |
5~7 |
||
| Bath volume(L) |
30 |
50 |
|
| Bath opening(mm) |
ф320×235 |
ф400×280 |
|
| Ambient temperature(°C) |
5~25 |
||
| Power Supply(V/Hz) |
380/50 |
||
| Overall Power(W) |
2400 |
5200 |
|
| Case Material |
SPCC steel with powder coating |
||
| Dimensions(mm) |
665L×545W×1010H |
1055L×850W×1345H |
|
| Weight(kg) |
100 |
150 |
|
| Model |
LLCP-20-80 |
LLCP-50-80 |
LLCP-100-80 |
|
| Temperature range(°C) |
-80~Room temp |
-80~Room temp |
-80~-40 |
|
| Temperature stability(°C) |
±1 |
|||
| Cooling capacity (W) | -40°C |
510 |
1150 |
2400 |
| -60°C |
210 |
760 |
1500 |
|
| -80°C |
80 |
300 |
600 |
|
| Flow(L/min) |
12 |
30 |
30 |
|
| Lift(m) |
5~7 |
10~12 |
||
| Bath volume(L) |
20 |
50 |
100 |
|
| Bath opening(mm) |
ф280×300 |
ф400×235 |
ф400×400 |
|
| Ambient temperature(°C) |
5~25 |
|||
| Power Supply(V/Hz) |
220/50 |
380/50 |
||
| Overall Power(W) |
2400 |
4800 |
9200 |
|
| Case Material |
SPCC steel with powder coating |
|||
| Dimensions(mm) |
905L×750W×1100H |
1010L×785W×1100H |
850L×1060W×1280H |
|
| Weight(kg) |
150 |
350 |
400 |
|
