※Product description:
Lighter flame height of the image detector to detect a single batch of five lighters, compatible with many types of lighters can set the relevant parameters according to the characteristics, it is possible to achieve lighter auto sampler, auto fire, auto-complete height of the flame, the flame is extinguished the fire and explosion, splashing fire, flame flashover and other testing.
The detection process can be displayed in real time lighter flame status parameters, eligibility to make a lighter sentence identification, automatic report generation after the end of the test and stored automatically. The instrument is equipped with an independent closed testing room to improve the detection of lighter safety.
※ Product parameters:
| Adaptation lighter type | Straight & Inclined& Grinders |
| Lighter size | Lighter height 63-83mm, width 21-25mm |
| Single Lot detection number | 5 |
| Flip positioning accuracy | ± 0.5 ° |
| Flame height measurement accuracy | 3mm |
| Flame height detection frequency | 25 frames / sec. |
| Flame height detection range | 0 ~ 200mm |
| Power supply | AC220/50（V/Hz） |
| dimension | 750×500×680（mm） |
