Main feature of Diaphragm Vacuum Pump
1. Excellent corrosion resistance: diaphragms, valve plates, air chambers, gas linesexhaust and exhaust joints and other parts that are in contact with other partsare made of corrosion-resistant materials such as PTFEFFKM and are suitable fola variety of complex environments.
2. High vacuum degree: ultimate pressure can reach 600 pa
3. Fast pumping: the pumping rate can reach 33L per minute
4. Strong power: 200 W power motor, strong power, large output torque, and stablespeed.
5. Low temperature rise: Reasonable air duct design and larger fan blades enablebetter motor heat dissipation, lower pump body temperature, and surfacetemperature not higher than 50℃.
6. Stable operation: The transmission mechanism has undergone special dynamicbalancing treatment, the amplitude of the machine body is small, and theoperation is stable.
7.New appearance design: After a new appearance design, the diaphragm pump issmaller in size and lighter in weight.
TECHNICAL PARAMETERS OF Diaphragm Vacuum Pump
| Model | DP-633 |
| Pumping rate | 3 3L/min |
| ultimate pressure | 600pa/6mbar |
| rated power | 200W |
| voltage | 200V 50HZ |
| Quantity of pumped air | 1 or 2 |
| Exhaust diameter | 7mm |
| Gas ballast function | have |
| Valve material | FFKM |
| Diaphragm material | PTFE+FKM |
| Gas line material | PTFE |
| Exhaust joint material | PTFE+C |
| Gas ballast material | PTFE+C |
| weight | 9.5kg |
