Features:
- Flexible customization about product size, shape.
- Compressor can be placed on backside or top of refrigerator
- Door can be open from front or side.
- Refrigerant: Environmental protection R406A.
- Material for the product: Stainless steel for inner & outer layer, also for the trays. Our standard configuration with the stainless steel is SS201. SS304 stainless steel and the other steel is optional.
- Each unit will be packed with 6 pcs strong quality universal wheel to be sure the unit is easy to move.
- Compressors: High quality compressor, the Germany High quality compressor is Optional, each compressor to control each chamber.
- Power: 220-240V/50Hz-60Hz, back up power (UPS) can supplier according to customer’s requirement.
- Temperature: The temperature set-value can be adjusted at -18℃~10℃, high-accuracy computer-controlled temperature system with original binding can maintain the temperature constancy in the box at 1-5℃precisely. Big temperature display on the top of the unit. And each chamber with one control button.
- Nice appearance. The integrated frame door design, to be sure the door is more tidy and nice.
- 5 kinds of alarms systems.
- Safety and closed lock door design.
Main technical parameter:
The normal dimension is as follows, it can be produce according to customer’s dimension requirement.
Model |
MR-CP1 |
MR-CP2 |
MR-CP3 |
MR-CP4 |
MR-CP6 |
MR-CP8 |
Bodies room |
1 |
2 |
3 |
4 |
6 |
8 |
Temperature |
-10℃~5℃ |
-10℃~5℃ |
-10℃~5℃ |
-10℃~5℃ |
-10℃~5℃ |
-10℃~5℃ |
Internal size |
1950*630*440 |
1950*630*440 |
1950*630*440 |
1950*630*440 |
1950*630*440 |
1950*630*440 |
Exterior size |
2460*800*610 |
2460*800*1200 |
2460*800*1700 |
2460*1580*1200 |
2460*1580*1700 |
2460*1580*1700 |
Weight |
150 |
300 |
450 |
600 |
600 |
600 |
Door number |
1 |
2 |
3 |
4 |
6 |
8 |
Material SS201 |
Yes |
Yes |
Yes |
Yes |
Yes |
Yes |
Material SS304 |
Optional |
Optional |
Optional |
Optional |
Optional |
Optional |
Wheels |
Yes |
Yes |
Yes |
Yes |
Yes |
Yes |
Compressor |
1 |
2 |
3 |
4 |
6 |
8 |
Temp. controller |
1 |
2 |
3 |
4 |
6 |
8 |
Temp. recorder |
Optional |
Optional |
Optional |
Optional |
Optional |
Optional |
Side open type
Model |
Temperature (Factory setting) |
Internal size(mm) |
Exterior size(mm) |
Weight KGS |
Bodies room |
MR-CP1S |
-18℃~10℃ |
2000*650*450 |
2500*820*620 |
150 |
1 |
MR-CP2S |
-18℃~10℃ |
2000*650*450 |
2500*820*1250 |
300 |
2 |
MR-CP3S |
-18℃~10℃ |
2000*650*450 |
2520*850*1870 |
450 |
3 |
Temperature: Factory setting is -18 to 10 ℃, user can adjust the temperature from -30 to 10 ℃.
