Application:
The Ultra-low Temperature Freezer offers a wide variety of research and storage applications, such as low temperature scientific experiments, preservation of red blood cell, white blood cell, skin, DNA/RNA, bone, bacteria, semen, biomedical product, ocean product, electronic devices, and low- temperature testing of special materials. It is suitable for blood banks, hospitals, sanitation, epidemic stations, electronic Industries, university laboratories, military industries, pelagic fishery companies.
Control System:
- Microprocessor-based temperature controller, -110°C ~ -152°C can be set freely , controlling precision is 1°C, Digital temperature display.
- Keyboard lock and password protected configuration page, Delayed start and safe stop interval between restart and being terminated
- Audible and visual alarm: High or low temperature alarm, Power failure alarm, Low battery alarm, Door open alarm, Filter blocking alarm, system failure alarm.
- With temperature printer, record 7days data. 72 hour battery backup for printer and controller display.
- Power supply: Normally 380V /50HZ 3 phase, can be changed as 220V 50/60HZ 1phase.
Structure Design:
- Chest type, Stainless steel interior, outer is painted steel panel, 4units Casters for easy handing
- Rotatable assistant door handle, Top door with key lock.
- Two-times foaming technology, double seal design. 155mm extra thickness heat insulation. VIP insulation technology.
- Optional: Chart recorder, LN back up, storage racks/boxes, Remote alarm system.
Refrigeration System:
- Imported famous Tecumseh compressor, with Germany EBM Fan motor
- Unique refrigeration circulation and unipolar compressor oil-lubricated technology
- China Patent technology of mixture refrigerant, which composed of R134a, R404a, R23, R410A, N2 and so on, CFC free
- Certificate: CE, ISO9001, ISO14001, ISO13485
Specifications:
Model |
MR-DF-UW128 |
MR-DF-UW258 |
Control system |
||
Temperature range |
-110°C ~ -152°C |
|
Temperature accuracy |
1°C |
|
Display |
LED display |
|
Alarm |
Visual & sound, High or low temperature alarm, Power failure alarm, Low battery alarm, Door open alarm, Filter blocking alarm, system failure alarm |
|
Keyboard lock |
Password protect |
|
Temperature recorder |
Printing recorder & * 72 hours |
|
Power supply |
380V/50Hz or 220V/50Hz |
|
Input power |
2600W |
3000W |
Refrigeration system |
||
Compressor |
DANFOSS |
|
Fan |
EMB (Germany) |
|
Refrigerant |
CFC free mixed |
|
Certificate |
CE/ISO 90001 13485 14001 |
|
Structure |
||
Capacity |
128L |
258L |
Style |
Chest type |
|
Inner material |
Stainless steel |
|
Outer material |
painted steel panel |
|
Caster |
4 pcs, 2 with brake |
|
Door handle |
full handle with key lock |
|
Insulation |
155mm thickness foaming layer, double seal |
|
External size. (WxDxH) mm |
880*1590*1040 |
890*2085*1009 |
Inside size (WxDxH) mm |
370*600*550 |
410*1140*552 |
Weight (N.t / G.t) |
215/250 kg |
260/330 kg |
Optional Items
MR860001 |
Chart recorder |
MR860002 |
LN standby system |
MR860003 |
Racks |
MR860004 |
Cryobox |
MR860005 |
Remote alarm system |
